C16 – STOPPING DISTANCE
CHECK
stopping distance on horizontal ground :
- The stopping distance is tested on flat ground with 1.1 times the nominal load in the basket.
- Reach maximum speed and then release the control.
Expected result:
On horizontal ground Stopping distance
Transport speed 1400 mm +or- 40 mm
Working speed 160 mm +or- 40 mm
Check brake holding on a slope
Place the nacelle on a nominal 25% slope static with 1.1 times the nominal load in the basket.
Expected result: no slipping of the nacelle must be detected after one minute.
3 - 23
647533 (09/10/2015)
MAN'GO 12
