Manitou MHT 10225 - Page 53

(25/11/2011)10-07-M184EN
10
6 ENGINE REFIT
Insert the hydraulic pump (Ref. 30) and  t the screws (Ref. 31).
Connect the temperature sensor (Ref. 33) to the thermostatic
valve (Ref. 32).
Connect all the electrical connections (Ref. 34) on the starter
motor (Ref. 35).
Connect all the electrical connections (Ref. 36) on the alternator
(Ref. 37).
31
30
32
33
34
35
36
36
37
