14 ENGINE REFIT
Re t the lubrication delivery pipe (Ref. 12) on the turbocompressor
by screwing in the  tting (Ref. 13).
Re t the suction hose (Ref. 14) on the turbocompressor (Ref. 1)
and tighten the clamp (Ref. 15).
Re t the suction hose (Ref. 16) on the air radiator and tighten
the 2 clamps (Ref. 17).
Re t the hose (Ref. 18) and tighten the clamp (Ref. 19).
13
12
1
14
15
17
16
17
18
19
