(25/11/2011)10-07-M184EN
10
18 ENGINE REFIT
Reconnect the upper hose (Ref. 16) on the pump and screw the
2 clamps (Ref. 17) back on.
Reconnect the lower hose (Ref. 18) on the pump and screw the
2 clamps (Ref. 19) back on.
Fill the cooling system tank (Ref. 20) with the liquid concerned;
the liquid level must be between the two notches indicating
the minimum and maximum levels (approx. 18 litres).
Remove the containers from under the engine compatment.
17
17
16
18
19
19
20
