MAINTENANCE
4.
89647852EN-USM1(B-12/2021)
6.6.Refit the nuts by hand, if necessary grease them.
6.7.Remove the security wedges and lower the lift
truck with the jack.
6.8.Tighten the wheel nuts with a torque wrench.
7. Replace front wheel
7.1.Lift the carriage and tilt the mast backwards.
7.2.Put wedges under the foot of the mast on the
side of the wheel to be changed.
7.3.Tilt the mast forwards to lift the wheel.
7.4.Place wedges under the chassis as near as
possible to the wheel.
7.5.Completely unscrew the wheel nuts and remove
them.
7.6.Free the wheel by reciprocating movements and
roll it to the side.
7.7.Slip the new wheel on the wheel hub.
7.8.Refit the nuts by hand, if necessary grease them.
7.9.Remove the wedges under the axle and lower
the lift truck.
7.10.Tighten the wheel nuts with a torque wrench.
