MAINTENANCE
4.
73647852EN-USM1(B-12/2021)
NOTICE
The fuel tank is degassed via the filler plug. When changing
it, always use an original part, with degassing hole.
The fuel level is shown by a fuel gauge.
As far as possible, keep the fuel tank well filled in
order to minimize condensation due to the
atmospheric conditions.
1. Remove cap (1).
2. Fill the fuel tank with clean diesel filtered through
the filling port.
3. Put back the cap (1).
4. Check visually that there is no leakage in the tank
and pipes.
4.7.4 CHECK HYDRAULIC FLUID
LEVEL
WARNING
Consult your dealer in case of abnormal operation of the
hydraulic controls.
Place the lift truck on level ground with the
engine stopped, the mast tilted backward and
lowered as far as possible.
1. Raise the engine cover.
2. Remove cap (1).
3. Refer to the dipstick (2).
A MI 15 / MI 18
B MI 20 / MI 25
C MI 30 / MI 35
4. The level is correct when it is between the MIN and
MAX markings on the dipstick.
5. Top up if necessary.
