6-16
Published 3/26/2018, Control # 596-05
SWING SYSTEM GRT8100 SERVICE MANUAL
FIGURE 6-5
3, 4
2
6
1
7, 8
9
7897-3
5
Item Description
1 20 Conductor Slip Ring Assembly
2Center Post
3 Capscrew
4 Flatwasher
5 Swivel Assembly
6 Retainer Plate
7 Capscrew
8 Flat Washer
9Plate
Picture may not be same model as your
machine, it is for reference only.
