Manitowoc Grove GRT8100 Service Manual

9-19
GRT8100 SERVICE MANUAL LUBRICATION
9
Published 3/26/2018, Control # 596-05
GROVE
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Outriggers
60 Wear Pads Figure 9-9 L --- 50 hours or 1 week Brush on
61 Outrigger Beams Figure 9-9 L --- 50 hours or 1 week Brush on
FIGURE 9-9
8600
61
61
61
61
61
61
60
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Lift Cylinder
70
Lower Lift
Cylinder Pin
Figure 9-10 L
Until grease
extrudes
500 hours or 3 months 1 grease fitting
8601
FIGURE 9-10
70
