LUBRICATION GRT8100 SERVICE MANUAL
9-12
Published 3/26/2018, Control # 596-05
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train (Continued)
7
Transmission
Filter
Figure 9-2
Change transmission filter after
first 50 and 100 hours of
service, then every 500 hours
thereafter
Refer to Item 5
NOTE.
8
Coolant Strainer
(Cab Heater)
Figure 9-2 --- ---
Clean strainer screen after
first 100 hours and every
2000 hours or 12 months
intervals thereafter.
Close shutoff valves.
Unscrew hex plug to
clean filter.
9
Fuel/Water
Separator
Figure 9-2 --- ---
Drain water trap every 10
hours or daily.
Water Separator is
located next to
hydraulic oil cooler.
NOTE: During replacement of the water separator, note direction of the arrow. Arrow must point toward fuel filter
10
Driveline - Slip
Joints
Figure 9-2 A
Until
grease
extrudes
500 hours or 3 months 2 grease fittings
FIGURE 9-2
10
10
9
FRONT
8592
7
8
To Next Page
