ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-18 Published 4-20-2015, Control # 502-01
5152 Seat Switch deadman input
5153 Armrest deadman switch input
5154 Both Deadman switches input
5160 Carrier Emergency Off Switch
5161 Carrier Emergency Off Relay input
5162 Carrier Emergency Operation input
5163 AMOT active input
5170 DPF Regen Init switch input
5171 DPF Regen Inhibit switch input
5300 Gas Pedal PWM input
5301 Slew Brake pedal PWM input
5302 Telescoping pedal PWM input
5303 Gas Pedal ANA input
5304 Service brake pedal ANA input
5305 Slewing brake pedal ANA input
5500 Cold Weather switch input
5501 Rear Wheels Not Centered switch input
5502 Differential Lock Front switch input
5503 Differential Lock Rear switch input
5504 Oil Temperature switch input
5505 Hydraulic oil temperature switch input
5506 Slewing system temperature switch input
5507 Starter Lockout
5509 All wheel drive active input switch
5510 Axle locking input switch
5511 Cross Diff Lock switch input Axle 1
5512 Cross Diff Lock switch input Axle 2
5513 Cross Diff Lock switch input Axle 3
5514 Cross Diff Lock switch input Axle 4
5515 Cross Diff Lock switch input Axle 5
5516 Cross Diff Lock switch input Axle 6
5517 Cross Diff Lock switch input Axle 7
5518 Cross Diff Lock switch input Axle 8
5519 Cross Diff Lock switch input Axle 9
5522 Long Diff Lock switch input Axle 2
5523 Long Diff Lock switch input Axle 3
5524 Long Diff Lock switch input Axle 4
5525 Long Diff Lock switch input Axle 5
Fault Code Component Description
