Manitowoc Grove RT540E Service Maintenance Manual

Published 4-20-2015, Control # 502-01 3-19
RT540E SERVICE MANUAL ELECTRIC SYSTEM
3
GROVE
5526 Long Diff Lock switch input Axle 6
5527 Long Diff Lock switch input Axle 7
5528 Long Diff Lock switch input Axle 8
5529 Long Diff Lock switch input Axle 9
5530 Drag link unlocked
5531 Drag link locked
5533 Steering Rod Lock switch input Axle 3
5534 Steering Rod Lock switch input Axle 4
5535 Steering Rod Lock switch input Axle 5
5536 Steering Rod Lock switch input Axle 6
5537 Steering Rod Lock switch input Axle 7
5538 Steering Rod Lock switch input Axle 8
5539 Steering Rod Lock switch input Axle 9
5600 Park Brake Pressure switch input
5601 ABS Trolley input
5602 Suspension group too high (front left) input
5603 Suspension group too high (front right) input
5604 Suspension group too high (rear left) input
5605 Suspension group too high (rear right) input
5606 Suspension group too low (front left) input
5607 Suspension group too low (front right) input
5608 Suspension group too low (rear left) input
5609 Suspension group too low (rear right) input
5700 Cab Sensor for Humidity
5800 Outrigger length left front analog input
5801 Outrigger length left rear analog input
5802 Outrigger length right front analog input
5803 Outrigger length right rear analog input
5804 Hoist limiter analog input
5805 Telescoping cylinder length analog input
5806 Stabilizer pressure sensor input, front left
5807 Stabilizer pressure sensor input, rear left
5808 Stabilizer pressure sensor input, front right
5809 Stabilizer pressure sensor input, rear right
5810 Anemometer analog input
5811 Angle sensor axle 1
5812 Angle sensor axle 2
5813 Angle sensor axle 3
Fault Code Component Description
Reference Only
