Manitowoc Grove RT540E Service Maintenance Manual

Published 4-20-2015, Control # 502-01 3-21
RT540E SERVICE MANUAL ELECTRIC SYSTEM
3
GROVE
5912 Derricking Down pressure switch
5913 Derricking Up pressure switch
5914 Telescoping Extend pressure switch
5915 Telescoping Retract pressure switch
5916 Hydraulic Oil Temp switch
5917 Brake Pressure switch
5918 AC Clutch Required switch
5919 Swing Right pressure switch
5920 Swing Left pressure switch
5921 Swing Brake pressure switch
5922 Hydraulic Oil Filter pressure switch
5923 Steering Pressure low switch
5924 Boom Section Locked redundant switch
5925 Left Tele Cylinder Locked redundant switch
5926 Right Tele Cylinder Locked redundant switch
5927 Left Tele Cylinder Pins Low switch
5928 Left Tele Cylinder Pins High switch
5929 Boom Section Locked switch
5930 Boom Section Unlocked switch
5931 Left Tele Cylinder Pin Unlocked switch
5932 Right Tele Cylinder Pin Unlocked switch
5933 Left Tele Cylinder Pin Locked switch
5934 Right Tele Cylinder Pin Locked switch
5935 Right Tele Cylinder Pins Low switch
5936 Right Tele Cylinder Pins High switch
5937 Jib mounted & folded switch
5938 Turntable Locked switch
5939 Turntable Unlocked switch
5940 Pump 1 Pressure analog input
5941 Telescoping Pressure analog input
5942 Slewing Pressure analog input
5943 Hoist Limiter (A2B) analog input
5944 Piston Length Sensor analog input
5945 8.5V External Feedback analog input
5946 Accumulator pressure sensor analog input
5947 Mechanical locking head TUSL switch
5948 Mechanical locking head TLSL switch
5949 Mechanical locking head TLSU switch
Fault Code Component Description
Reference Only
