ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-22 Published 4-20-2015, Control # 502-01
5950 Auxiliary Hoist Indenitifier input
5951 New York House Lock Pin Bolted input
5952 New York House Lock Locked input
5953 New York House Lock Unlocked input
5954 Counterweight Left Unlock input
5955 Counterweight Right Unlock input
5956 Counterweight Left Lock input
5957 Counterweight Right Lock input
5958 Counterweight Left Bottom Proximity Switch input
5959 Counterweight Right Bottom Proximity Switch input
5960 Counterweight Left Top Proximity Switch input
5961 Counterweight Right Top Proximity Switch input
5962 Hoist Limiter (A2B) Switch input - Stop
5963 Steering Filter switch input
5964 Flow indicator steering circle 1
5965 Flow indicator steering circle 2
5966 Air Filter switch input
5967 Cabin locked left switch input
5968 Cabin locked right switch input
5969 Bridge collision switch input
5970 Filter backpressure switch input 1
5971 Filter backpressure switch input 2
5972 Length Hydraulic pivot cylinder
5973 Auxhoist right locked
5974 Auxhoist left locked
5975 Auxhoist right unlocked
5976 Auxhoist left unlocked
5977 Auxhoist carrier retracted
5978 Counterweight installed input
5979 Counterweight in position input
5980 Counterweight position left analog input
5981 Counterweight position right analog input
5982 Derricking valve spool position analog input
5983 Slew left pressure analog input
5984 Slew right pressure analog input
5985 Hoist Limiter (A2B) Switch input - Slow
6000 PERM 24V voltage output
6001 Release LMI output
Fault Code Component Description
