Published 4-20-2015, Control # 502-01 3-23
RT540E SERVICE MANUAL ELECTRIC SYSTEM
6002 Gearshift power supply output
6003 SCM0 ignition to CCM10 output
6004 SCM0 ignition to CCM11 output
6005 Oil Cooler Off relay output
6006 SCM0 ignition to IOS modules output
6007 SCM0 ignition to displays output
6008 Accessory output
6010 Turn signal left output
6011 Turn signal right output
6020 Left armrest lamps output
6021 Right armrest lamps output
6030 Perm VCC output
6031 Boom Lights 1 output
6032 Boom Lights 2 output
6033 IOL30 Sensor supply output
6034 Aircraft Warning Light output
6035 Horn output
6036 AC Condenser Motor output
6037 Windshield Washer output
6038 Beacon Lights output
6039 IOS20 Sensor Supply output
6040 Lamp Main hoist output
6041 Lamp Derricking output
6042 Lamp Telescoping output
6043 Lamp Jib output
6044 Lamp Park Brake output
6045 Lamp Slewing output
6046 Lamp Aux Hoist output
6047 Flight traffic light output
6048 Release hoist limiter
6049 IOL34 Sensor supply output
6050 New York House Lock change direction output
6051 New York House Lock release direction output
6060 Windshield Wash front Wiper
6061 Windshield Wash top Wiper
6062 Delay Front Wiper
6063 Delay Top Wiper
6064 Windshield Wash front Wiper low speed
Fault Code Component Description
Reference Only
