ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-24 Published 4-20-2015, Control # 502-01
6065 Windshield Wash front Wiper high speed
6066 Windshield Wash front Wiper park
6100 Headlight Low Beam Left output
6101 Headlight Low Beam Right output
6102 Brake Lights output
6103 Engine Start output
6104 AC Clutch output
6105 Marker Lights output
6106 Reverse Lights output
6107 Derricking Release output
6108 Daytime Driving Light output
6109 Fuel Heater Relay output
6110 Enable Cross (Transverse) Differential Locks Output
6111 Enable Longitudinal Differential Locks Output
6112 Enable Axle Blocking Output
6113 Unlock Axle 3 Steering Output
6114 Unlock Axle 4 Steering Output
6115 Unlock Axle 5 Steering Output
6116 Unlock Axle 6 Steering Output
6117 Unlock Axle 7 Steering Output
6118 Unlock Axle 8Steering Output
6119 Unlock Axle 9 Steering Output
6120 Superstructure Maneuvering Enable Output (EDM)
6121 Select Gear D Output (EDM)
6122 Select Gear N Output (EDM)
6123 Select Gear R Output (EDM)
6124 PTO Request Output (EDM)
6125 Inhibit Upshift Output (EDM)
6126 Inhibit Engine Start Output
6127 Switch carrier/super cabin
6128 Central lubrication
6130 Air Conditioning ON output
6131 Air Conditioning (Superstructure) output
6132 Air Conditioning (Carrier) output
6133 Retarder (Telma brake) output
6134 Fog tail lights output
6135 Fog lights output
6136 High beam headlight
Fault Code Component Description
