RT540E SERVICE MANUAL ELECTRIC SYSTEM
6137 Outrigger Light Front Left Output
6138 Outrigger Light Front Right Output
6139 Outrigger Light Rear Left Output
6140 Outrigger Light Rear Right Output
6200 Four Wheel Drive output
6201 Rear Axle Oscillation output
6202 Rear Steer Right output
6203 Rear Steer Left output
6204 Park Brake Release output
6205 Differential Lock output
6206 Load Sense output
6210 Stabilizer Left Front solenoid
6211 Stabilizer Right Front solenoid
6212 Stabilizer Left Rear solenoid
6213 Stabilizer Right Rear solenoid
6215 Beam Left Front solenoid
6216 Beam Right Front solenoid
6217 Beam Left Rear solenoid
6218 Beam Right Rear solenoid
6220 Outrigger Extend solenoid
6221 Outrigger Retract solenoid
6225 Transmission Forward solenoid
6226 Transmission Reverse solenoid
6227 Transmission First Gear solenoid
6228 Transmission Second Gear solenoid
6229 Transmission Third Gear solenoid
6230 Transmission Fourth Gear solenoid
6231 Transmission Fifth Gear solenoid
6240 Pressure buildup solenoid
6241 Release All Wheel steering solenoid
6244 Steering Control Valve 1 solenoid
6245 Steering Control Valve 2 solenoid
6246 Steering Control Valve 3 solenoid
6247 Slewing System Release solenoid
6248 Block Steering Circuit 1 solenoid
6249 Service Brake solenoid
6250 AMOT valve solenoid (Air intake valve)
6251 Steer Left solenoid Axle 1
Fault Code Component Description
