ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-26 Published 4-20-2015, Control # 502-01
6252 Steer Left solenoid Axle 2
6253 Steer Left solenoid Axle 3
6254 Steer Left solenoid Axle 4
6255 Steer Left solenoid Axle 5
6256 Steer Left solenoid Axle 6
6257 Steer Left solenoid Axle 7
6258 Steer Left solenoid Axle 8
6259 Steer Left solenoid Axle 9
6261 Steer Right solenoid Axle 1
6262 Steer Right solenoid Axle 2
6263 Steer Right solenoid Axle 3
6264 Steer Right solenoid Axle 4
6265 Steer Right solenoid Axle 5
6266 Steer Right solenoid Axle 6
6267 Steer Right solenoid Axle 7
6268 Steer Right solenoid Axle 8
6269 Steer Right solenoid Axle 9
6270 Stabilizer Left Front extend solenoid
6271 Stabilizer Right Front extend solenoid
6272 Stabilizer Left Rear extend solenoid
6273 Stabilizer Right Rear extend solenoid
6274 Stabilizer Left Front retract solenoid
6275 Stabilizer Right Front retract solenoid
6276 Stabilizer Left Rear retract solenoid
6277 Stabilizer Right Rear retract solenoid
6278 Extension Beam Left Front extend solenoid
6279 Extension Beam Right Front extend solenoid
6280 Extension Beam Left Rear extend solenoid
6281 Extension Beam Right Rear extend solenoid
6282 Extension Beam Left Front retract solenoid
6283 Extension Beam Right Front retract solenoid
6284 Extension Beam Left Rear retract solenoid
6285 Extension Beam Right Rear retract solenoid
6286 Suspension Group Left Front solenoid
6287 Suspension Group Right Front solenoid
6288 Suspension Group Left Rear solenoid
6289 Suspension Group Right Rear solenoid
6290 Axle Lifting Front Left solenoid
Fault Code Component Description
