ELECTRIC SYSTEM RT540E SERVICE MANUAL
3-34 Published 4-20-2015, Control # 502-01
35 The internal supply voltage UC2 is too low
36 Analog Input error
37 Digital Input error
38 Digital Output error
39 PWM Output error
40 Task Time too long
41 Data is not valid
42 Device is not operational
43 Could not get semaphore
44 Data does not match required data
45
The counter from a connected CAN device is no longer
being updated. The data is considered no longer valid.
46 A CAN device is reporting a self-detected error
47
The pinning system could not unlock within the required
time limit
48 The current operating mode is invalid
49 Movement in opposite direction
50 Unintentional Lock
52 The internal supply voltage UF is too low
53 The internal supply voltage UE is too low
54 The internal supply voltage UF is out of range
55 The internal supply voltage UB1 is out of range
56 The internal supply voltage UB2 is out of range
57 The internal supply voltage UC1 is out of range
58 The internal supply voltage UC2 is out of range
59 The external supply voltage EXT is out of range
60 Outrigger base too small
61 Jib angle tolerance
128
The last reset was because the watchdog detected that
Ue was above the maximum allowed value
129
The last reset was because the watchdog detected that
Ue was below the minimum allowed value
130
The last reset was because the watchdog detected that
the system voltage was above the maximum allowed
value
131
The last reset was because the watchdog detected that
the system voltage was below the minimum allowed value
132
The last reset was because the watchdog detected an
error as defined by the user
133
The last reset was because the watchdog detected a
system error
Fault Code Condition Description
