Manitowoc Grove RT540E Service Maintenance Manual

INTRODUCTION RT540E SERVICE MANUAL
1-4 Published 4-20-2015, Control # 502-01
Lift Cylinder & Lower Shaft 218.0 (85.85) 638 (1407) 381 (839) 258 (568)
Complete Basic Machine
4 x 4 chassis; Cummins QSB 6.7 Tier 4
engine w/ transmission; front and rear axles;
20.5 x 25 tires; main hoist
w/137 m (450 ft) of 5/8 in. 6 X 37 cable; full
fuel and hydraulic oil
170.36 (67.07) 27209 (59986) 12674 (27940) 14536 (32046)
Add To Basic Unit Weight
7.9 to 13.7 m (26 to 45 ft) Tele Boom
Extension
616.36 (242.66) 745 (1642) 1255 (2767) -510 (-1125)
Boom Ext. Carrier Brackets (Bolt On) 543.56 (214.00) 116 (256) 172 (380) -56 (-124)
Auxiliary Boom Nose - Installed
1018.95
(401.16)
48 (105) 133 (293) -85 (-188)
36 metric ton (40 ton) CE Hookblock (4 - 14
in sheaves) Stowed in Tray
396.24 (156.00) 351 (774) 381 (839) -29 (-65)
36 metric ton (40 ton) Hookblock (3 - 14 in
sheaves) Stowed in Tray
396.24 (156.00) 283 (623) 306 (675) -24 (-52)
36 metric ton (40 ton) Hookblock (3 -12 in
sheaves) Stowed in Tray
396.24 (156.00) 272 (599) 294 (649) -23 (-50)
7 metric ton (7.5 Ton) Headache Ball
(Swivel) - Attached to Front O/R Box
581.66 (229.00) 167 (369) 266 (587) -99 (-218)
Storage Tray Mats 337.82 (133.00) 20 (43) 18 (40) 1 (3)
Rear Mounted Pintle Hook -162.56 (-64.00) 5 (11) -2 (-5) 7 (16)
Driver Controlled Differential Locks 177.80 (70.00) 19 (41) 9 (20) 10 (21)
Russian Certification Package 127.00 (50.00) 28 (61) 10 (21) 18 (40)
Air Conditioning - Carrier and superstructure
components
38.10 (15.00) 44 (98) 5 (10) 40 (88)
360 Degree Swing Lock 205.74 (81.00) 29 (64) 16 (36) 13 (28)
Driver 187.96 (74.00) 113 (250) 58 (128) 55 (122)
CE Components - w Main Hoist 10.16 (4.00) 285 (628) 8 (17) 277 (611)
CE Components - w Main & Aux Hoists 15.24 (6.00) 274 (603) 11 (25) 262 (578)
Remove: Auxiliary Hoist Cable (453 ft) of 5/8
35 x 7
-121.92 (-48.00) -179 (-394) 59 (131) -238 (-525)
Remove: Main Hoist Cable (450 ft) of 5/8 6 X
37
-60.96 (-24.00) -174 (-383) 29 (64) -203 (-447)
Add: Aux Hoist (Replace IPO Cwt With Aux
Hoist and Cable)
-109.22 (-43.00) 174 (383) -52 (-114) 225 (497)
Sub: Optional Cable on Main Hoist (453 ft of
5/8 inch 35 X 7)
-60.96 (-24.00) 5 (11) -1 (-2) 6 (13)
Sub: Tier 3 Engine -157.48 (-62.00) -17 (-37) 7 (16) -24 (-53)
Sub: Kessler Axles 175.26 (69.00) -86 (-190) -41 (-91) -45 (-99)
Sub: 16.00 X 25 Titan Tires 182.88 (72.00) -64 (-140) -32 (-70) -32 (-70)
Description
CG From Rear
Axle cm (in)
Weight
kg (lb)
Front Axle
kg (lb)
Rear Axle
kg (lb)
Reference Only
