Manitowoc Grove RT540E Service Maintenance Manual

Published 4-20-2015, Control # 502-01 8-3
RT540E SERVICE MANUAL UNDERCARRIAGE
8
GROVE
FIGURE 8-1
10
11
5
6
7
9
17
12
15
16
8
3
19
20
18
4
1
1
1
1
2
21
4
3
2
14
13
5
Item Description
1 Cotter Pin
2Pin
3Pin
4 Lockout Cylinder
5 Steer Cylinder
6 Grease Fitting
7Pin Weld
8Pin Weld
9 Capscrew
10 Lockwasher
11 Flatwasher
Item Description
12 Capscrew
13 Washer
14 Hex Nut
15 Capscrew
16 Lockwasher
17 Flatwasher
18 Sensor Plate
19 Capscrew
20 Lockwasher
21 Rear Axle
Reference Only
