HYDRAULIC SYSTEM RT540E SERVICE MANUAL
2-28 Published 4-20-2015, Control # 502-01
SUPERSTRUCTURE
6726
2
5
6
4
3
1
FIGURE 2-14
Item Description
1 Hoist/Telescope/Lift Directional Valve
2 Swing/Steer Directional Valve
3 Service Brake Dual Accumulator Charge Valve
Item Description
4 Secondary Steer Valve (CE Option)
5 Accumulator
6 Superstructure
1
Reference Only
