HYDRAULIC SYSTEM RT880E SERVICE MANUAL
2-26 Published 11-10-2014, Control # 524-00
P1 Piston Pump
Item Description
1 Procedure A - Main Control Valve Pressure for Hoists, Boom Lift, Telescope
- Check/Adjust - Step No. 3 (Maximum Pressure)
2 Procedure I - Swing Brake Release Pressure - Check/Adjust - Step No. 3
7748-02
FIGURE 2-10
1
2
