6
CEILING CASSETTE 875 AIR THROWS
AIRFLOWS OUTDOOR / DUCTED UNITS
MIN Speed MAX Speed Min. Speed Max. Speed
Model CFM m
3
/s CFM m
3
/s Model CFM m
3
/s CFM m
3
/s
MCU+ 60 -
1250 0.59 1660 0.78
DCUE 60
885 0.42 1115 0.53
MCU+ 80 -
1250 0.59 1660 0.78
DCUE 80
740 0.34 1040 0.48
MCU+ 90 MHPUL(E) 80
1440 0.68 2420 1.14
MCU+ 100 -
1440 0.68 2420 1.14
Note: On MCU+ and MHPUL the minimum speed
can fall to zero under fan speed control if the
ambient temperature is low
(to maintain good operating conditions).
MCU+ 130 MHPUL(E)100
2840 1.34 3690 1.74
MCU+ 150 MHPUL(E) 150
2840 1.34 3690 1.74
FRESH AIR SUPPLY (see page 56 for kit details)
CC 875 units are fitted with an inlet to allow the installer to provide a fresh air supply
The 100mm dia. spigot is available as kit 55200305.
The installer must provide ductwork, a screened source of fresh air and an auxiliary
fan.
The auxiliary fan must be sized to overcome the resistance of the filter, the ductwork
and the cassette itself. (To prevent excessive noise, the maximum fresh air volume
should be less than 5% of the nominal air volume for any given unit and fan speed).
The auxiliary fan should be connected to a separate electrical circuit, appropriately
fused and isolated.
