Root Chapter 3: Operation
www.masimo.com 36 Masimo
The area where all data from a docked Radical-7 or
connected MOC-9 module are displayed.
Select to see Trend View of the parameters and
measurements, if supported.
Select to see Analog View of the parameters and
measurements, if supported.
Shows a parameter or measurement over time (only for
Radical-7 and MOC-9 modules).
(Available only in Trend View) Parameters and
measurements are shown as Trend Displays in Trend View.
A parameter or measurement's Trend Display includes its
Value Range, Numeric Value, Alarm Limits and Parameter
label. See Using Trend View on page 37.
(Available only in Analog View) Parameters and
measurements are shown as Analog Gauges in Analog
View. A parameter's Analog Gauge includes its Alarm
Limits, Numeric Value, Parameter Label, as well as
Alarming, Caution and Normal Ranges. See Using Analog
View on page 38.
(Available only in Trend View). Shows the amount of time
the parameter or measurement has been monitored.
Increase or decrease the time frame shown by using the
pinch or spread gestures respectively.
(Available only in Trend View). Adjust the Time Frame by
preset increments using the "+" and "-" buttons.
Displays parameters and measurements which are not
shown as Trend Displays or Analog Gauges.
