Masimo Root RDS-7 User Manual

Root Chapter 3: Operation
www.masimo.com 41 Masimo
Customizing Windows
Windows can be customized by expanding and minimizing parameters and
measurements in both Trend View and Analog View. When a parameter is
minimized, it is only displayed the Well with its Numeric Value and Parameter
Label. When a parameter is expanded, it will be shown as either a Trend
Display or Gauge.
To expand a parameter or measurement
Order
Instruction
Step 1
Press and hold the Numeric Value until it dims.
Step 2
Drag the Numeric Value over any Trend Display.
Step 3
Release the Numeric Value.
