100
Item Description Quantity
Q02 Shroud;Right Front 1
Q03 Shroud;Rear 1
Q04 Shroud;Left Front 1
Z09 Screw (M8 x 60L) 4
Z13 Screw (M10 x 75L) 2
Z14 Screw (M10 x 15L) 4
Lift the wing and front cover, then assemble the front
and rear shields to the frame.
CHAPTER 5: ASSEMBLY INSTRUCTIONS
5.12 G7-S57 CALF EXTENSION ASSEMBLY INSTRUCTIONS - CONTINUED
STEP 4
