152
CHAPTER 6: TROUBLESHOOTING
ARMS ARE NOT EVEN AT THE STARTING POSITION
POSSIBLE CAUSES
1) The arm tie rods are uneven.
2) The arms are bent or uneven.
3) The frame is bent or uneven.
SOLUTION
1) The tie rods on the Shoulder Press, Chest Press, Lat Pull Down and Seated Row are adjustable.
a. If the arms are uneven, loosen the jam nuts and adjust the tie rods as needed to level the arms. Tighten the jam nuts to hold the arms
in place.
2) Place a level along multiple points on each arm to determine if the arms are bent or if it is the frame.
a. Replace the unit or arms as needed.
FIGURE A
6.3 TROUBLESHOOTING - ARMS ARE UNEVEN
