Matrix G7 Strenght User Manual

178
7.18 HEAD PAD REPLACEMENT
CHAPTER 7: PART REPLACEMENT INSTRUCTIONS
1) Remove the 2 screws holding the head pad / back cover to the frame (Figure A). NOTE: One of the screws may be covered by the U frame
(Figure B).
2) Remove the head pad / back cover (Figure C).
3) Reverse Steps 1-2 to install a new head pad.
FIGURE A FIGURE B
FIGURE C
