Matrix G7 Strenght - 7.19 Back Pad Replacement

179
7.19 BACK PAD REPLACEMENT
1) Remove the 2 screws holding the back pad / back cover to the frame (Figure A).
2) Remove the back pad / back cover (Figure B).
3) Reverse Steps 1-2 to install a new back pad.
FIGURE A
FIGURE B
CHAPTER 7: PART REPLACEMENT INSTRUCTIONS
