Matrix G7 Strenght User Manual

155
6.6 TROUBLESHOOTING - ABDOMINAL UPPER ARMS UNEVEN
ABDOMINAL UPPER ARMS ARE UNEVEN
POSSIBLE CAUSES
1) The bolt / nut holding the upper arm frame to the main frame are not tight enough.
SOLUTION
1) Tighten the bolt / nut holding the upper arm frame to the main frame (Figure A). This bolt / nut should be tightened to 100 N-m torque.
FIGURE A
