122
Lift the aluminum wing and top cover, then take apart the front and
rear shields. Q11 bolts will not be used anymore for the wing and
cover re-assembly.
Item Description Quantity
B52 Flat Washer (M10) 8
Z02 Lock Washer (M10) 4
Z09 Screw (M10 x 75L) 4
Z13 Nut (M10) 4
STEP 1
5.16 G7-S73 PRONE LEG CURL ASSEMBLY INSTRUCTIONS - CONTINUED
CHAPTER 5: ASSEMBLY INSTRUCTIONS
