49
CHAPTER 5: ASSEMBLY INSTRUCTIONS
5.4 G7-S23 SHOULDER PRESS ASSEMBLY INSTRUCTIONS - CONTINUED
Lift the wing and top cover, then assemble the
front and rear shields to the frame.
Item Description Quantity
Q02 Right Front Cover 1
Q03 Rear Cover 1
Q04 Left Front Cover 1
Z17 Screw (M8 x 60L) 4
STEP 6
