62
5.6 G7-S34 SEATED ROW ASSEMBLY INSTRUCTIONS - CONTINUED
Item Description Quantity
Q02 Right Front Shield 1
Q03 Rear Shield 1
Q04 Left Front Shield 1
Z27 Screw (M8 x 60L) 4
Lift the wing and front cover, then assemble the
front and rear shields to the frame.
STEP 6
CHAPTER 5: ASSEMBLY INSTRUCTIONS
