10. Installation
It is strongly recommended that at least two persons perform the installation!
10.1. Tools required for Assembly
The following tools are not included in the scope of delivery:
• Protective gloves
• Work platform (e.g. ladder) according to the local occupational safety regulations.
• Level or Digital Protractor
• Cable routing aid (ideally 400 mm cable tie type Colson)
• Testing weight of 3.0 kg (e.g. a weighed canister of water)
Standard tool set including:
• Torx T10 screwdriver
• Medium sized slotted (flat-headed) screwdriver
• 24 mm open-ended wrench
• 24 mm socket for torque wrench
• Allen keys (sizes 2.5, 5, 8)
• Torque wrenches capable of providing torques 2 Nm, 10 Nm and 100 Nm
