10.18.5. Side Panels
See Figure 38.
Installation:
1. Place both side panels ⑨.
2. Carefully engage the latches ⑩ on the side panels
3. Check, that the side panels ⑨ are securely in place:
• The side panels ⑨ must sit against each other without gaps.
Disassembly:
1. Gently disengage the latches ⑩ on the side panels ⑨.
2. Take off both side panels ⑨
Figure 38 Spring Arm Covers
