Extension Arm Ceiling Column Bottom
Cover
Screws M4x10
Cover blade rear
12 E-7110133 Securing Element Axis C
13 E-7110134 Brake Screws Axis B & C, M10, 10x
14 E-7110129 Brake Screws Axis A M10, 10x
15 E-7110130 Securing Elements Axis B, 10x
16 E-7110124 Securing Element Axis A, 10x
17 E-TS152X
Installation Kit TS152X
4x Screw M10x35 DIN 912 type 10.9
4x Washers M10 DIN 125-A
4x Snap Ring M10 DIN 127
1x Loctite 270 10 ml
To Next Page
