Maxair CAPR - Glossary; Temperature

Page 111 P/N 03521015 Rev Q
28.3.10 Projected LIB Level Available As A % At Initial Manufacture Versus
Temperature
Year(s)
Elapsed from
Manufacture
Date
Storage Condition: 50% charged
Storage Condition: 100% charged
Residual
Capacity (due to Self-
Discharge)
Recoverable
Capacity
Residual
Capacity
(due to Self-
Discharge)
Recoverable
Capacity
23°C 60°C 23°C 60°C 23°C 60°C 23°C 60°C
1 96% 76% 99% 92% 90% 60% 94% 80%
2 92% 52% 98% 84% 80% 20% 88% 60%
3 88% 28% 97% 76% 70% 0% 82% 40%
4 84% 4% 96% 68% 60% 0% 76% 20%
5 80% 0% 95% 60% 50% 0% 70% 0%
Year(s)
Elapsed from
Manufacture
Date
Self-Discharge Loss
Permanent Capacity
Loss
Self-Discharge Loss
Permanent Capacity
Loss
23°C 60°C 23°C 60°C 23°C 60°C 23°C 60°C
1 4% 24% 1% 8% 10% 40% 6% 20%
2 8% 48% 2% 16% 20% 80% 12% 40%
3 12% 72% 3% 24% 30% 100% 18% 60%
4 16% 96% 4% 32% 40% 100% 24% 80%
5 20% 100% 5% 40% 50% 100% 30% 100%
28.3.11 Glossary
LIB
Lithium Ion Battery, Li-Ion Battery
Self Discharge
The rate at which the battery charge level declines while it is just sitting in storage, usually quoted as a decline in
%-per-month.
Self-discharge increases with age, cycling and elevated temperature.
Discard a battery if the self-discharge reaches 30 percent in 24 hours.
Recoverable Capacity
The amount that a battery can be “fully charged back to” over time, usually quoted as a certain % of the full charge
level when the battery was initially manufactured.
