5. Standard System Set Up
5.1 Components Check List
Required Components
ITEM O.N. NIOSH P/N QTY DESCRIPTION
1 2081-03 03531001, 03531021, 01031269, 2590-05 1ea MAXAIR CAPR Helmet Assembly
2
2365-02SM or
2365-02ML
01031316 OR 01031291
40/
Box
Disposable Lens Cu󰀨 (DLC) - Small/
Medium (SM) or Medium/ Large (ML)
3 2500-36TSC 01532104 1ea Li-Ion Battery
4 2600-01 01432089 1ea Li-Ion Battery Charger
5 2000-76 2000-76 1ea Battery Belt
5.2 Setting Up
1. Check the position of the Headband Comfort Strips. (See Section 7 for Comfort Strip assembly and replacement instructions).
2. Adjust the Rear Headband Ratchet Adjustment Knob counterclockwise to expand the Headband circumference to ensure the
Helmet will t easily before donning. (See Section 6 on Donning for more detail.)
3. Adjust the Height Adjustment Snaps on the Helmet Liner to ensure proper and secure t of the CAPR System on the head
and good visibility of the Safety Status Indicator LEDs. (See Section 6 for more detail.)
4. Check to ensure that the Helmet Power Cord is rmly attached to the Helmet Power Cord Connector.
5.3 Assemble and Disassemble Components
CAUTION
Prior to operation, review all components’ Instructions For Use regarding set-up, assembly/disassembly,
and don/do󰀨 in sections 6,10-19.
The general assembly/disassembly steps are as follows:
STEP ASSEMBLE STEP DISASSEMBLE
4
Assemble the 2061-08
Filter Cover Cap to the Helmet.
(Alternate Covers are
appropriate for other
congurations.)
2
If required, disassemble
the 2061-08 Filter Cover
Cap from the Helmet.
3
Snap o󰀨 the 2051-07 SnapOn
Cage and snap on the 2164-
10 Filter Cartridge from the
Helmet.
(Alternate Filter Cartridges may
be used.)
3
If required, disassemble
the 2164-10 Filter
Cartridge from the Helmet.
(Dispose appropriately as
hazardous waste.)
1
Inspect and ready the
2081-03 Helmet for use.
5
If required, prep the
2081-03 Helmet for
storage.
2
If required, assemble the
2071-01 Helmet Liner to the
Helmet.
4
If required, disassemble
the 2071-01 Helmet Liner
to the Helmet.
5
Assemble the DLC to Helmet.
(Alternate Face/Head covers
may be used for other
congurations.)
1
Disassemble the DLC.
(Dispose of the DLC
appropriately as
hazardous waste.)
