Maxair CAPR - Applicability of Earlier Version Components and Assemblies; Filter Cover Cap (FCC), 2061-08 (01031284)

Page 25 P/N 03521015 Rev Q
3.4.1 Filter Cover Cap (FCC), 2061-08 (01031284)
The current version FCC, 2061-08, includes a right-side and a left-side snap on the rear half of the FCC Skirt (A), and a front
Long Adapter (B).
The snaps are to secure the top of the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and 2261-01ML/SM, respectively.
These snaps were included in the most recent 2061-03 version as well.
The front adapter, added only on the 2061-08, eliminates the need to change front adapters when switching between Cu󰀨 &
Shroud congurations and Hood congurations.
The original version of the 2061-03 FCC does not include these snaps or the front adapter(C) and must not be used with the
DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and 2261-01ML/SM, respectively.
When upgrading older DLC CAPR Systems to use them with the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM
and 2261-01ML/SM, respectively, you must upgrade to the newer version of the 2061-03 with the side rear snaps, or, most
preferably, the new 2061-08 FCC with the rear side snaps and the front adapter.
NOTE
The new version of the 2061-03 FCC was included with your 2074-04 Helmet Kits and 2061-03 FCCs if purchased after
September 2012.
WARNING
If you have CAPR Helmets with Filter Cover Caps, 2061-03, with lot numbers with a lower number than 1209007-N,
inspect them for the presence of the rear snaps on each side (A). If they are not there, you must replace those FCCs
with newer versions with the snaps to safely use the DLC-Shroud and DLC-Double Shroud, 2260-05ML/SM and
2261-01ML/SM, respectively, with your CAPR Helmets.
3.4. Applicability of Earlier Version Components and Assemblies
A
B
C
2061-08
2061-03
