Air Flow Switch Position
Low Med High
Air Flow in Liters Per Minute
190 215 240
9 Side Adjustment Straps with Snaps - Height adjustment. Four holes represent four possible height adjustments
to accommodate di󰀨erent head sizes and ensure convenient viewing of the LED Safety Status Indicators. Secure into desired
position by snapping against post/stud. Both sides are to be in the same hole position.
10 Rear Liner Pads - Provide cushion for comfort. Attached via adhesive. For replacement refer to Section 29,
Accessories.
11 Rear Headband Comfort Pad - Provides cushion for comfort and sizing for very small head sizes. Attached
via Hook and Loop, and removable. For replacement, refer to Section 29.
12 Rear snaps for Liner - For mounting LIner to Helmet
13 Liner Headband Ratched Knob - Head circumference adjustment knob.
14 Helmet Label - PN, O.N. and SN identication. Refer to symbol denition chart for further details.
15 TurnLock Power Cord Connector - Easy and secure attachement and removal of Power Cord to/from Helmet.
16 Liner Power Cord Slot - Allows removal and attachment of Liner without removaing Power Cord
17 Airow Controller - Allows user to select range of air ow to me work activity and personal comfort
CAUTION
The Air Flow Switch is user adjustable to match the amount of air ow with the user’s activity level and breathing
requirements.
NOTE
The ow levels, in liters per
minute, are only approximate.
NOTE
When the Helmet is initially connected to the Battery, all ve LED Safety Status Indicators are lighted briey indicating
all are functional. The red and yellow LEDs will turn o󰀨 and the airow increases to the appropriate operating level based on the
Air Flow Switch position. The green LEDs will be on as appropriate to the battery charge level as indicated in the LED Safety
Status Indicators table (previous page).
CAPR Helmets are equipped with a switch which adjusts the operating airow. When the Helmet is rst turned on it will start at a
low level, then the airow will increase to a preset point according to the switch position.
18 Power Cord - Battery to Helmet Connection. For replacement, refer to Section 24, Helmets and Helmet Accessories.
