Page 69 P/N 03521015 Rev Q
Donning
8. Connect the Helmet Power Cord to
the Battery. Push the Power Cord
Connector into the Battery Receptacle
until the Secure Connection audibly
clicks.
9. Loosen headband Ratchet
Knob (counterclockwise).
10. Hold Helmet in one hand and pull Cu
down with other hand. Place chin inside
cu and pull helmet down onto head.
11. Secure Helmet by tightening Ratchet Knob as tight as
comfortably possible, while ensuring stability. The front
headband should sit within ½ inch of eyebrows for good
visualization of the Safety LEDs.
12. Pull back of shroud up, over, and down behind helmet.
Slide ngers between face and cu on both sides from
chin to temples to ensure a slight Cu-to-Face tension.*
WARNING
* If there is a lack of tension, switch to 2260-05SM,
and repeat beginning with step 3.
13. Secure shroud by pulling ties around the waist and tying in
the front. Pull neck ties around to the front and tie securely.
Leaving about a ½ inch gap between neck and Shroud.
14. Optionally, tuck Shroud inside body cover.
Dong
Reverse steps 8 thru 14 to do Helmet and remove Shroud.
After disconnecting the Battery from the Helmet, connect it
to the Charger.
WARNING
Refer to Section 9, page 43, Instructions For
Use: Charger, for details on proper use of
chargers and for charging batteries.
To Next Page
