FIFE-500 MAX Narrow Web Guide
MI 2700XXXXX 18
CHAPTER 4
ASC SETTINGS
43 / 77
Above +
Signal is greater than the positive threshold. The negative
threshold is not used.
Below –
Signal is less than the negative threshold. The positive
threshold is not used.
Outside +/-
Signal is less than the negative threshold or greater than the
positive threshold.
Below +
Signal is less than the positive threshold. The negative
threshold is not used.
Above –
Signal is greater than the negative threshold. The positive
threshold is not used.
Inside +/-
Signal is greater than the negative threshold and less than
the positive threshold.
ASC Threshold
Positive:The ASC signal positive threshold. Touch the threshold value to
open an edit screen to change it.
Negative:The ASC signal negative threshold. Touch the threshold value to
open an edit screen to change it.
Delay:
On: ASC will be enabled after a set time when the configured ASC threshold
reaches the trigger range.
Off: When the configured ASC threshold is not in the trigger range, ASC will
be disabled after the set time.
Press ACCEPT to save changes and return to the previous screen.
Press CANCEL to exit without saving changes and return to the
previous screen.
