FIFE-500 MAX Narrow Web Guide
4.19 DLS-8 This menu is used to guide the operation of the DLS-8sensor.
The screen appears differently depending on the port where the DLS-8 is
connected to the guiding system. The sensor parameter setting section for
unconnected ports will be grayed out and cannot be set.
(Only port S1 is connected) (Port S1 and port S2 are connected )
Setting：
1) Click on this button and if this is your first calibration, you will see
the screen 1A.3.3.1 :
Click to return to screen 1A.3.
Click on this button to go to Step1 and perform the calibration
preparation actions according to the following screen prompts
(you can see the green step prompt progress bar at the top of
the screen, and each step will be prompted):
