56
J-BOX COVER
3. Replace J-box cover as shown in FIG. 56-1.
Torque bolts to 18 - 20 lb-ft.
ATTACHING J-BOX COVER
FIG. 56-1
HEX BOLT,
5/16”-18 X 4-3/4” LG.
(4 PLACES)
FENDER WASHER,
5/16” X 3/4” O.D.
(4 PLACES)
LOCK NUT,
5/16”-18
(4 PLACES)
STEP 6 - ATTACH STOW LIGHT TO TRAILER - Continued
