12MXT 28000
66 M1
14.2.6 Adjusting the minimum capacity of the
engine (speed of travel)
1- Place the machine on stabiliser support, with wheels
raised; forward movement with high speed engaged,
engine in maximum regime.
2- Read the speed in rpm by placing an optoelectronic
sensor on the universal gear joint.
3- Turn the screw (1 fig. 1) anti-clockwise to increase the
number of rpm.
19 flat spanner
6 male hexagonal spanner
Optoelectronic sensor
1
Operation
Speed
(rpm)
Measurement
(ref. no.)
Adjustment
(ref. no.)
Minimum capacity
FRANCE 25 km/h
2,510 (+30 -30) Joint 1 fig. 1
Minimum capacity
GERMANY 20 km/h
2,080 (+30 -30) Joint 1 fig. 1
Fig. 1 Transfer movement engine
