CashFlow
952X / 952Xe / 9510 User Guide
MEI., 2005 Page 37 Rev: G2
CF9510 - SW8 - Multi-pulse Teach
On the CF9510, SW8 is used to enter Multi-pulse Teach Mode. As with Parallel Output
Teach Mode, the unit must be power-cycled for the switch setting to be acknowledged.
Again, for this operation, the LED will blink green a number of times followed by one red
blink. The number of green blinks equates to the number of pulses to be set and can be
changed by pressing the reject lever. The maximum number of pulses that can be set via the
MMI for each coin is 4. However 8 can be set using the support tool, if necessary.
Number of Reject Lever Presses 0 1 2 3
N° Of Green Flash Code 1 2 3 4
Number of Pulses Selected 1 2 3 4
