19 Emergency exit
Conveying systems which cross an emergency exit route
must separate at the appropriate point (e.g. using a folding
conveyor table, see photo).
The sections of the conveyor system must separate as
quickly as possible in case of emergency.
We are happy to advise on this matter if required.
20 Noise levels
In accordance with the 3rd regulation of the German Law on Appliance Safety, noise levels
are below 70 dB (A).
Hand force on handle upwards
approx. 2–5 kp (20–50 N)
Closed position
Stop
Open position
Pneumatic
springs
Contact switch for
electrical safety
Handle
