mensor PCS 400 - Page 106

Dual Gauge Pressure with Barometric Reference Transducer
SUPPLY
SOURCE
REFERENC
E
EXHAUST
EXHAUST
OUTPUT
REGULATOR
ASSEMBLY
MEASURE/
CONTROL
FILTER
FILTER
VENT
1/3 PSI
CHECK
VALVE
CONTROL
SHUTOFF
SOLENOID
OUTPUT
SHUTOFF
SOLENOID
1PSI
RELIEF
VALVE
PRIMARY XDCR
RELIEF VALVE
ALTERNATE XDCR
RELIEF VALVE
P
P
P
P
L5
L3
L1
COARSE
SUPPLY
SOLENOID
COARSE
EXHAUST
SOLENOID
L2
AUX
XDUCER
PRIMARY
XDUCER
(GAUGE)
SECONDARY
XDCR SHUTOFF
SOLENOID
R
R
L6
SECONDARY
XDUCER
(GAUGE)
BARO REF
XDUCER
(ABSOLUTE)
SPT
#00
(STANDARD)
SPT
#01
(OPTIONAL)
SPT
#02
(OPTIONAL)
ALL SOLENOID VALVES ARE 2-WAY NORMALLY CLOSED (N.C.).
NOTE:
VENT
SOLENOID
L4
FILTER
Figure 9.4 - Pneumatic Schematic
PCS 400 APPENDIX
www.mensor.com 9-13
