Isolate/Re-inst ate Shunt Group
One or more circuits can be assigned to the shunt group, this is normally done by your
alarm company although the master user can also configure the circuits that are assigned
to the shunt group, see “Alter Shunt Group” on page 31. Once a shunt group has been
defined this option allows the you isolate and re-instate the circuits that are assigned to the
shunt group.
User menu 1
Select Option :-
SYSTEM OPEN
17:30 01 JAN
CCTS ISOLATED
09:45 01 JAN
1 -
OPEN
CCTS
ISOL
6 6 6
1 1 1
2 2 2
? ? ? ?
ENT
+
? ? ? ?
ENT
+
? ? ? ?
ENT
+
LCD Remote St arburst Remote
LED Rem ote
Isolating a Shunt Group
1. From the unset (open) mode enter your passcode and press [ENT] to select user
menu 1.
2. Whilst user menu 1 is selected. Press [6] to select the isolate/Re-instate shunt group
option.
3. The system will automatically return to the open mode and the display will indicate
that circuits are isolated.
19
