Mercury Avator 7.5e User Manual

Description Nm lb‑in. lb‑ft
Fasteners 13.6 120 10
75335
10. Verify that the outboard anti‑ventilation plate is in‑line or within 25 mm (1
in.) of the bottom of the boat.
a - Anti‑ventilation plate
b - In‑line or within 25 mm (1
in.)
QUICK-DISCONNECT DISABLE SCREW – TILLER MODELS ONLY
This is a method to disable the quick‑disconnect mechanism from operating.
This provides a more permanent installation where portability is not required.
This method may discourage theft of the outboard.
1. Locate the torx screw hole on the transom bracket.
2. With the outboard fully installed into the transom bracket, install the torx
screw on the outboard.
a
b
75513
INSTALLATION
 40 eng

Mercury Avator 7.5e Specifications

General

Power Source	Electric
Control	Tiller
Mounting	Transom
Operating Voltage	48V
Power	750W
Engine Type	Electric motor
Run Time	Up to 1 hour at full throttle
Propeller	3-blade
Warranty	2 years
Shaft Length	Short
